Airfoil 5kW
Designed to install at rooftop to supply power for facilities such as commercial building, factory, distribution center and shopping facility as supplement to utility and symbol of environmental friendly. It’s also good unit to install on the ground because of features of Airfoil 5K.
Past Projects
-
October 2015
Aichi5kW (Grid connection type)
The first 5kW type. Installed as a power supply for a 10-story multistory parking yard.
System configuration
| Windmill | Structure | monopole |
|---|---|---|
| Blade Length | 5m (16.4ft) | |
| Blade Rotation Diameter | 4.5m (14.76ft) | |
| Number of Blades | 4 | |
| Blade Width | 1300mm (4.2ft) | |
| Blade Material | Anti-Rusting Aluminum | |
| Weight | 620kg (1364lb) | |
| Total Height with Pole | 7.5m (24.6ft) | |
| Generator | Specifications | PMSG |
| Rated Output (at 12 m/s wind velocity) | 5KW | |
| System Function | Minimum Rotating Wind Velocity | 1.8m/sec (4mph) |
| Kick-in Wind Velocity | 2.8m/sec (6.3mph) | |
| Survival Wind Velocity | 60m/sec (134.4mph) | |
| Voltage | AC200V | |
| Battery (Owner supplied, reference only) | - | |
| Grid Connection | Yes in USA | |
| System | Independent | |
| Grid | ||
| Solar Panel | Option | |
| Co-Operation with Utility * | Option | |
| Typical Application | Building Roof |
The specification is subject to change without notice.
* This is the device to switch to utility power when the wind turbine output is not enough.
